名称：磨齿机

型号：ZSTZ25（35）

产地：德国尼尔斯

年限：1983年

max tip circle dia                                                           3500mm

min root circle dia                                                          350mm

max face width                                                              1000mm

min /max module                                                            4--34

min/max number of teeth                                                16-600

min /max helix angle                                                        0 -35

max table load                                                                30000kg

round table dia                                                                2000mm

table bore dia                                                                  480mm

depth of the table bore                                                     460mm

min/max distance steady-table                                 770-1670mm

steady bore                                                                       90mm

grinding worm dia/ -width                                     300-400/80mm

grinding wrom drive                                                          24kw

griding wrom spindle speed                                   1200-6300rpm

max grindability profile depth                                              50mm

rapid feet axial/radial                                              6000/3000mm

total power                                                             approx 50kw

machine weight                                                     approx 48000kg

space requirement(wxdxh)                        10200x7615x4500mm
